Goodrive880 Series Inverter Unit Hardware Manual
No.
3
4
5
6
7
8
9
10
11
12
3.3.5.7 Layout and mounting for 2*A8i inverter frame
Figure 3-33 shows the layout for 2*A8i inverter frame.
Nameplate
Frame
Unit tray
202311 (V1.0)
Name
Magnet ring assembly
Unit top fixed beam
Unit bottom fixed plate
(+) busbar and busbar clamp
(-) busbar and busbar clamp
Busbar clamp fixed support
Side air baffle assembly (with sealing sponge)
Output reactor base
Copper bar between unit and reactor
Output to motor side copper bar
Figure 3-33 Layout of 2*A8i inverter frame
525
Lifting hole
Inverter unit
Output copper bar
Footing
Grounding sign
Mechanical installation
600
47
