Goodrive880 Series Inverter Unit Hardware Manual
Unit model
GD880-51-0340-6-XX
GD880-51-0410-6-XX
GD880-51-0530-6-XX
GD880-51-0600-6-XX
GD880-51-0650-6-XX
GD880-51-0720-6-XX

2.10.3 Contactor

A contactor connects and disconnects DC circuit and automatically switches between precharge circuit and
bus main circuit. The same brand replacement principle should be followed. See the following table for
selection.
Unit model
GD880-51-0516-4
GD880-51-0639-4-XX
GD880-51-0757-4-XX
GD880-51-0900-4-XX
GD880-51-0410-6-XX
GD880-51-0530-6-XX
GD880-51-0600-6-XX
GD880-51-0650-6-XX
GD880-51-0720-6-XX
Note:
A BUB precharge component is optional for A1i–A4i units. For details, see section

component.
Selection is unnecessary for the A6i/A7i units which support built-in precharge component.

GD880-51-0516-4 doesn't support built-in precharge component.

202311 (V1.0)
Frame size Voltage (V)
A7i
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
Frame size Voltage (VDC)
A7i
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
A8i/A8n/A8L2
Current (A)
1000 630
1000 1600
1000 1600
1000 1600
1000 1600
1000 1600
Current (A)
48 600
48 600
48 600
48 600
48 600
48 600
48 600
48 600
48 600
Product overview
Qty
1
1
1
1
1
1
Qty
1
2
2
2
2
2
2
2
2
6.2 BUB precharge
24
