Goodrive880 Series Inverter Unit Hardware Manual
A8i inverter unit

1
2
3
4
5
No.
1
2
3
4
5
6
7
8
9
10
11
12
202311 (V1.0)
Figure 2-14 Structure of A8i unit
6
Module top fixing hole
User terminals on the fiber optic and control boards
Handle
Fan cover plate
Module bottom fixing hole
Anti-tipping stand
Female connector, mounted and fixed to the cabinet
(+) and (-) bus input copper bar
Lifting-ring mounting holes (two M12 threaded holes)
Nameplate
Pulley
UVW AC output terminals
8
9
10
7
11
Description
Product overview
12
16
