5 Inverter Control Unit (ICU)

5.1 ICU composition

No. Component
1 Slot 1
Battery cover
2
3 Indicator
4 Slot 2
5 Nameplate
6 SD card
202311 (V1.0)
1
2
3
4
5
6
7
8
9
10
Table 5-1 Components
Applied to 73.5×103×23.5(mm) function expansion modules and
communication expansion card
Button battery replacement cover. The internal button battery is a non
plate rechargeable lithium battery that needs to be replaced regularly.
Power supply, fault, running indicator
Applied to
communication expansion card, and optical fiber expansion card
Nameplate information
Standard microSD memory card, flexible to plug and unplug, capacity:
32GB
13 12
11
16
Function description
73.5×103×23.5(mm)
Inverter Control Unit (ICU)
14
15
function expansion modules,
73
