Goodrive880 Series Inverter Unit Hardware Manual
Model
GD880-51-0023-4
GD880-51-0033-4
GD880-51-0038-4
GD880-51-0048-4
GD880-51-0060-4
GD880-51-0078-4
GD880-51-0094-4
GD880-51-0116-4
GD880-51-0149-4
GD880-51-0183-4
GD880-51-0245-4-XX
GD880-51-0299-4-XX
GD880-51-0349-4-XX
GD880-51-0395-4-XX
GD880-51-0516-4
GD880-51-0639-4-XX
GD880-51-0757-4-XX
GD880-51-0900-4-XX
GD880-51-0975-4-XX
GD880-51-1213-4-XX
GD880-51-1439-4-XX
GD880-51-1710-4-XX
GD880-51-1852-4-XX
GD880-51-2158-4-XX
GD880-51-2565-4-XX
GD880-51-2778-4-XX
GD880-51-3420-4-XX
GD880-51-3704-4-XX
GD880-51-4275-4-XX
GD880-51-4630-4-XX
GD880-51-5130-4-XX
GD880-51-5556-4-XX
Note:
It is recommended to use the heavy overload mode for A1i–A4i.

Models (-HC) with a built-in precharge are available for A6i–A7i structures, but GD880-51-0516-4 does

not have models with a built-in precharge.
The A8 structure offers A8i, A8n, A8L2, and K structures (A8i is a fast-connector structure with built-in

output reactors and rear outlets, supporting frame supply; A8n is a direct connection structure without
output reactors, with front outlets; A8L2 is a direct connection structure with built-in output reactors
and front outlets; K is a frame structure).
The model with structure A8i needs to add fast connector components V-SK03A4-3Z.1 according to the

number of units.
202311 (V1.0)
510–720VDC (Rectifier incoming voltage: 3PH 380–440VAC）
Light overload
Ratings
application
I I P I
N max N Ld
A (AC) A (AC) kW A (AC)
23 27 11 22
33 40 15 32
38 51 18.5 37
48 59 22 45
60 72 30 58
78 96 37 75
94 120 45 91
116 146 55 112
149 179 75 143
183 240 90 176
245 294 110 236
299 358 132 287
349 419 160 335
395 486 200 380
516 619 250 495
639 766 355 613
757 909 400 727
900 1080 500 864
975 1170 560 945
1213 1456 630 1165
1439 1727 800 1381
1710 2052 1000 1642
1852 2222 1100 1795
2158 2590 1200 2072
2565 3078 1400 2463
2778 3333 1500 2693
3420 4104 1800 3283
3704 4444 2000 3590
4275 5130 2400 4104
4630 5556 2500 4488
5130 6156 2800 4925
5556 6666 3000 5386
Heavy overload
application
P I P
Ld Hd Hd
kW A (AC) kW
11 17 7.5
15 25 11
18.5 32 15
22 37 18.5
30 45 22
37 60 30
45 75 37
55 91 45
75 112 55
90 150 75
110 184 90
132 224 110
160 262 132
200 296 160
250 387 200
315 479 250 A8i/A8n/A8L2
400 568 315 A8i/A8n/A8L2
450 675 355 A8i/A8n/A8L2
500 731 400 A8i/A8n/A8L2
630 910 500 2*A8i/A8n/A8L2
800 1079 630 2*A8i/A8n/A8L2
900 1283 710 2*A8i/A8n/A8L2
1000 1388 800 2*A8i/A8n/A8L2
1200 1619 900 3*A8i/A8n/A8L2
1400 1924 1000 3*A8i/A8n/A8L2
1500 2083 1100 3*A8i/A8n/A8L2
1800 2565 1400 4*A8i/A8n/A8L2
2000 2776 1500 4*A8i/A8n/A8L2
2200 3206 1800 5*A8i/A8n/A8L2
2500 3471 1900 5*A8i/A8n/A8L2
2800 3848 2000 6*A8i/A8n/A8L2
3000 4166 2300 6*A8i/A8n/A8L2
Product overview
Heat
dissipation
Structure
kW
A1i 0.19
A2i 0.29
A2i 0.31
A2i 0.41
A3i 0.51
A3i 0.61
A3i 0.75
A4i 0.78
A4i 1.2
A4i 1.5
A6i 1.8
A6i 2.2
A7i 2.6
A7i 3.2
A7i 5.2
6.8
8
10
10.1
13.6
16
20
21.2
24
30
31.8
40
42.4
50
53
60
63.6
Air
volume
m³/h
17
68
68
94
110
128
179
255
255
255
1000
1000
1000
1000
1000
1500
1500
1500
1500
3000
3000
3000
3000
4500
4500
4500
6000
6000
7500
7500
9000
9000
6
