Goodrive880 Series Inverter Unit Hardware Manual
When installing or maintaining the A8n and A8n and A8L2 inverter units in a cabinet, to make it convenient for
the inverter module to enter or exit the cabinet, it is necessary to use the inverter unit installation
maintenance bracket. The installation and maintenance bracket is shown in the following figure, and the
operation method is shown in section
Figure 6-3 Installation and maintenance bracket dimensions (unit: mm)
541.00
202311 (V1.0)
Figure 6-2 Installation rail dimensions (unit: mm)
7.2.4 Inverter
823.25
778.00
201
135
unit.
245.00
Accessories
13
541.00
305.00
86
