Goodrive880 Series Inverter Unit Hardware Manual

2.2 Product nameplate and model

Note: The preceding nameplate is a standard product nameplate example. The marking varies slightly
depending on the model.
The model designation code contains basic product information such as rated current and rated voltage.
You can find the model designation code on the product nameplate.

2.3 Product ratings

Model
GD880-51-0009-4
GD880-51-0013-4
GD880-51-0017-4
202311 (V1.0)
Figure 2-1 Product nameplate
Figure 2-2 Product model
GD880 - 51 - 0600
Product type
51: Inverter unit
Product series
GD880: Goodrive880 series engineering VFD
Table 2-2 Product ratings of AC 3PH 380V–440V
510–720VDC (Rectifier incoming voltage: 3PH 380–440VAC）
Light overload
Ratings
application
I I P I
N max N
A (AC) A (AC) kW A (AC)
9 11 3.7 9
13 15.6 5.5 13
17 21 7.5 17
Model: GD880-51-0900-4
Power(Output): 500kW
Input: DC 510~720V
Output: AC 0~0.7*VDC 900A
S/N:
Shenzhen INVT Electric Co.,Ltd
K
- 6 -
Unit module
Empty: standard unit
K: Frame type
N: A8n module
L2: A8L2 unit
HC: Built-in precharge
LC: Water-cooled product
Voltage class
4: AC 3PH 380V–440V
6: AC 3PH 520V–690V
Rating
0600: 600A
Heavy overload
application
P I P
Ld Ld Hd Hd
kW A (AC) kW
3.7 5.1 2.2
5.5 9 3.7
7.5 13 5.5
Product overview
IP00
Made in China
Heat
Structure dissipation
kW
A1i 0.1
A1i 0.14
A1i 0.17
Air
volume
m³/h
17
17
17
5
