Product Overview; Product Specifications - INVT Goodrive880 Series Hardware Manual

Goodrive880 Series Inverter Unit Hardware Manual
For Goodrive880-51 series inverter units, the rated power of a single unit is 3.7kW–710kW, while that of
parallel units can be up to 6500kW. The inverter unit consists of bus capacitor and IGBT, and some models
carry built-in reactors. It is compact in structure and easy to integrate and maintain.

2.1 Product specifications

Function description
Power input
Output voltage (V) 0–0.7*Vin
Output current (A) See section
Power Output power (kW) See section
output
Working efficiency ≥98.5% (at the rated current)
Control
performance
Environment
condition
Mechanical
data
Protection function
202311 (V1.0)

2 Product overview

Table 2-1 Product specifications
510–720VDC, corresponding to AC 380–440VAC ±10%,
-15%<1min
Input voltage (V)
700–1035VDC, corresponding to AC 520–690VAC ±10%,
-15%<1min
Input current (A) See section
Output frequency
0–400
(Hz)
Space voltage vector control, sensorless vector control (SVC),
Control mode
and feedback vector control (FVC) mode
Motor type Asynchronous motor (AM) and synchronous motor (SM)
Speed ratio For AM, 1:200 (SVC); for SM, 1:20 (SVC), 1:1000 (FVC)
For AMs: 0.25Hz/150% ( SVC)
Starting torque
For SMs: 2.5Hz/150% (SVC); 0Hz/200% (FVC)
Stable speed
±0.2% (SVC); ±0.02% (FVC)
accuracy
Dynamic speed
0.4–0.5%s (SVC); 0.2–0.3%s (FVC) (100% torque step)
drop
Torque accuracy ±5% (SVC, >5Hz); ±3% (FVC)
Torque response <10ms (SVC); <5ms (FVC)
Working -10°C – +50°C; Derating is required when the ambient
temperature temperature exceeds 40°C.
Relative humidity 5%–95%, no condensation
Installation Below 1000m (Derating is required when the altitude exceeds
altitude 1000m. Derate by 1% for every increase of 100m.)
Anti-vibration
Compliant with 3M4 vibration level in GB/T4798.3
performance
For the module: IP00
IP rating
For the cabinet: IP20 (Optional: IP23 and IP42)
Safety
Compliant with EN 61800-5-1
performance
Cooling method Forced air cooling
Including functions of protection against short circuit,
overcurrent, overload, overvoltage, undervoltage,
overtemperature, and phase loss
Specifications
