Goodrive880 Series Inverter Unit Hardware Manual
3*A8i frame

8
1
5
No.
1
2
3
4
5
6
7
8
9
10
11

2.9 System configuration

Figure 2-20 shows a typical common DC bus drive system.
The rectifier module converts AC voltage to DC voltage, and the DC voltage is distributed to all inverter
modules through the DC bus, then the inverter modules convert the DC voltage to AC voltage to drive the
motor to rotate. An external DC fuse is required for the connection between each inverter module and DC
bus.
202311 (V1.0)
Figure 2-19 Structure of 3*A8i frame
9
Frame
A8i inverter unit
Inverter unit (+) and (-) bus input copper bar
Fixing holes on the back of the frame
Anchor bolt (for transportation fixing)
UVW AC output terminals
Insulation protective plate
Lifting hole
Ground (PE) terminal
Bottom slide rail
Frame bottom mounting holes
3
2
11
Description
Product overview
4
7
6
10
21
