Goodrive880 Series Inverter Unit Hardware Manual
Remove (+), (-) DC input copper bar
Remove two screws at the bottom of the unit
202311 (V1.0)
Figure 7-4 Replacing the A8n inverter unit
Remove the protective plate
Maintenance and inspection
Remove the protective plate
Remove two fixing screws at the top of the unit
Remove six M6*25 screws connecting
the copper bar between the reactor
base and the unit.
