Goodrive880 Series Inverter Unit Hardware Manual
incoming cable
①
No.
1
2
3
4
5
6
7
8

2.10 Electrical model selection

2.10.1 DC fuse

A fuse protects the rectifier unit and DC bus in case of short circuit, avoiding thermal overload. The same
brand replacement principle should be followed. See the following table for selection.
Unit model
GD880-51-0009-4
GD880-51-0013-4
GD880-51-0017-4
GD880-51-0023-4
GD880-51-0033-4
GD880-51-0038-4
GD880-51-0048-4
GD880-51-0060-4
GD880-51-0078-4
GD880-51-0094-4
GD880-51-0116-4
GD880-51-0149-4
GD880-51-0183-4
202311 (V1.0)
Figure 2-20 System configuration
Power
③
DC
②
AC
AC main circuit breaker
Rectifier unit
DC fuse
(Optional) Isolation switch
(Optional) DC contactor
(Optional) Precharge resistor
Inverter unit (each consisting of two modules)
Motor
Frame size
A1i
A1i
A1i
A1i
A2i
A2i
A2i
A3i
A3i
A3i
A4i
A4i
A4i
④
⑥ ⑤
DC DC
⑦
AC
M
⑧
3~
Description
Voltage (V)
690
690
690
690
690
690
690
690
690
690
690
690
690
DC
AC AC
M
3~
Current (A)
16
25
32
40
63
80
100
125
160
160
200
250
315
Product overview
Qty
2
2
2
2
2
2
2
2
2
2
2
2
2
