Goodrive880 Series Inverter Unit Hardware Manual
No. Component
7 Slot 3
8 Power interface 24V power input terminal
Fiber optic
9
interface
10 RJ45 terminal
11 User terminal
12 STO terminal
13 RJ45 terminal
14 Fixed hole
15 RJ45 terminal
Fiber optic
16
interface

5.2 LED indicator

No. Name
1 POWER
2 Fault
3 RUN
202311 (V1.0)
Applied to 73.5×74×23.5(mm)
communication expansion card, and optical fiber expansion card
Master/slave fiber optic interface
Upper computer interface, connecting to a PC for status monitoring
Standard input and output terminals for users
Safe Torque Off input
HMI, connecting to the SOP-880 keypad
ICU fixing holes (three holes)
Communication interface with power unit (inverter A1–A4, A6, A7 units)
Fiber optic communication interface with power unit (inverter A8 unit)
Table 5-2 Indicator description
State
ON
OFF The ICU is not powered or power failure occurs.
ON
OFF
ON
OFF
Function description
function
Description
The ICU is properly powered.
The system is faulty.
The system is normal.
The power module is running.
The power module is stopped.
Inverter Control Unit (ICU)
expansion modules,
74
