Goodrive880 Series Inverter Unit Hardware Manual
Model
GD880-51-0062-6-XX
GD880-51-0082-6-XX
GD880-51-0099-6-XX
GD880-51-0125-6-XX
GD880-51-0144-6-XX
GD880-51-0192-6-XX
GD880-51-0217-6-XX
GD880-51-0270-6-XX
GD880-51-0340-6-XX
GD880-51-0410-6-XX
GD880-51-0530-6-XX
GD880-51-0600-6-XX
GD880-51-0650-6-XX
GD880-51-0720-6-XX
GD880-51-0779-6-XX
GD880-51-1007-6-XX
GD880-51-1140-6-XX
GD880-51-1235-6-XX
GD880-51-1368-6-XX
GD880-51-1510-6-XX
GD880-51-1710-6-XX
GD880-51-1853-6-XX
GD880-51-2052-6-XX
GD880-51-2280-6-XX
GD880-51-2470-6-XX
GD880-51-2736-6-XX
GD880-51-3088-6-XX
GD880-51-3420-6-XX
GD880-51-3705-6-XX
GD880-51-4104-6-XX
GD880-51-4940-6-XX
GD880-51-5472-6-XX
GD880-51-6175-6-XX
GD880-51-6840-6-XX
Note:
Models (-HC) with a built-in precharge are available for A7i structures.

The A8 structure offers A8i, A8n, A8L2, and K structures (A8i is a fast-connector structure with built-in

output reactors and rear outlets, supporting frame supply; A8n is a direct connection structure without
output reactors, with front outlets; A8L2 is a direct connection structure with built-in output reactors
and front outlets; K is a frame structure).
202311 (V1.0)
Table 2-3 Product ratings of AC 3PH 520V–690V
700–1035VDC (Rectifier incoming voltage: 3PH 520
Light overload
Ratings
application
I I P I
N max N Ld
A A
kW A (AC)
(AC) (AC)
62 74 55 60
82 98 75 79
99 118 90 95
125 150 110 120
144 173 132 138
192 230 160 184
217 259 200 215
270 323 250 260
340 408 315 326
410 492 400 394
530 636 500 509
600 720 560 576
650 780 630 624
720 864 710 690
779 935 800 748
1007 1208 1000 967
1140 1368 1100 1094
1235 1482 1200 1186
1368 1642 1300 1311
1510 1813 1400 1450
1710 2052 1600 1642
1853 2223 1800 1778
2052 2462 2000 1967
2280 2736 2000 2189
2470 2964 2400 2371
2736 3283 2600 2622
2850 3420 2800 2736
3420 4104 3200 3278
3705 4446 3600 3557
4104 4925 4000 3934
2736 5928 4800 4744
5472 6566 5200 5244
6175 7410 6000 5930
6840 8208 6500 6555
–
Heavy overload
application
P I P
Ld Hd Hd
kW A (AC) kW
55 46 45
75 61 55
90 74 75
110 94 90
132 108 110
160 144 132
200 162 160
250 202 200
315 255 250
355 308 315 A8i/A8n/A8L2
450 398 355 A8i/A8n/A8L2
560 450 400 A8i/A8n/A8L2
560 488 450 A8i/A8n/A8L2
630 540 500 A8i/A8n/A8L2
710 584 560 2* A8i/A8n/A8L2
900 755 710 2* A8i/A8n/A8L2
1000 855 800 2* A8i/A8n/A8L2
1000 927 900 2* A8i/A8n/A8L2
1200 1026 1000 2* A8i/A8n/A8L2
1400 1133 1100 3* A8i/A8n/A8L2
1600 1283 1200 3*A8i/A8n/A8L2
1600 1390 1300 3*A8i/A8n/A8L2
1800 1539 1500 3*A8i/A8n/A8L2
2000 1710 1600 4*A8i/A8n/A8L2
2000 1854 1800 4*A8i/A8n/A8L2
2400 2052 2000 4*A8i/A8n/A8L2
2400 2138 2000 5*A8i/A8n/A8L2
3200 2565 2400 5*A8i/A8n/A8L2
3200 2782 2600 6*A8i/A8n/A8L2
3600 3078 3000 6*A8i/A8n/A8L2
4000 3708 3600 8*A8i/A8n/A8L2
4800 4104 4000 8*A8i/A8n/A8L2
5000 4635 4500 10*A8i/A8n/A8L2
6000 5130 5000 10*A8i/A8n/A8L2
