Goodrive880 Series Inverter Unit Hardware Manual
2*A8i frame

8
1
5
No.
1
2
3
4
5
6
7
8
9
10
11
202311 (V1.0)
Figure 2-18 Structure of 2*A8i frame
9
Frame
A8i inverter unit
Inverter unit (+) and (-) bus input copper bar
Fixing holes on the back of the frame
Anchor bolt (for transportation fixing)
UVW AC output terminals
Insulation protective plate
Lifting hole
Ground (PE) terminal
Bottom slide rail
Frame bottom mounting holes
3
2
11
Description
Product overview
4
7
6
10
20
