Goodrive880 Series Inverter Unit Hardware Manual
Figure 3-26 shows the installation of two A8i inverter units with the precharge function in a cabinet.
Figure 3-26 Installing two A8i inverter units with the precharge function in a 600mm-wide cabinet
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
202311 (V1.0)
1
2
3
4
5
6
Input copper bar
Precharge module
Magnet ring assembly
Unit top fixed beam
Unit bottom fixed plate
(+) and (-) busbars and busbar clamps
Busbar clamp fixed support
Isolation switch
Side air baffle assembly (with sealing sponge)
Fast connector female end
Output copper bar
Bottom outgoing hole
7
8
9
10
12
13
Name
DC fuse
