Goodrive880 Series Inverter Unit Hardware Manual
Terminal
No.
symbol
AO1
Analog
GND
output
AO2
Jumper J6: Selection between AO1 voltage and current signal outputs
1 2 3
I U
1 2 3
U
I
Jumper J7: Selection between AO2 voltage and current signal inputs
3
1 2
U
I
1 2 3
I U
Relay 1 output terminal
1 RO1A
2 RO1B
3 RO1C
Relay 2 output terminal
1 RO2A
2 RO2B
3 RO2C
Relay 3 output terminal
1 RO3A
2 RO3B
3 RO3C
Master/slave fiber optic
1 TX
2 RX
Safe torque off terminal
1 STO1
2 +24V
3 STO2
4 +24V
RJ45 keypad
1 RJ45
RJ45 Ethernet
1 RJ45
202311 (V1.0)
Function description
AO output range:
0–20mA, Rload≤500Ω
0–10V, Rload≥10kΩ
Resolution: 11 bit+signbit
Accuracy: 2% of full scale range
When 1 and 2 are short-circuited, AO1 current output is used.
When 2 and 3 are short-circuited, AO1 voltage output is used.
When 1 and 2 are short-circuited, AO2 current output is used.
When 2 and 3 are short-circuited, AO2 voltage output is used.
Output type: passive NO and NC
contacts
Contact parameters: 250Vac/30Vdc, 3A
Output type: passive NO and NC
contacts
Contact parameters: 250Vac/30Vdc, 3A
Output type: passive NO and NC
contacts
Contact parameters: 250Vac/30Vdc, 3A
Transmitting
communication
Receiving optical fiber communication
Inverter module STO input
They has been short connected before
delivery by default.
Connected to SOP-880-01 keypad
Ethernet communication with a PC
Two-core twisted-pair cable is
recommended.
Cross-sectional area: 0.5–2.5mm²
AO1 and GND, AO2 and GND use
twisted-pair cables.
Single-core wire
Cross-sectional area: 0.5–2.5mm²
Single-core wire
Cross-sectional area: 0.5–2.5mm²
Single-core wire
Cross-sectional area: 0.5–2.5mm²
optical fiber
Dedicated fiber optic cable
Four-core shielded twisted-pair
cable
Cross-sectional area: 0.5–2.5mm²
Standard shielded network cable
Standard shielded network cable
Inverter Control Unit (ICU)
Cable specifications
81
