Operations
Item
Inputting step ladder programs as ladder
diagrams
Inputting step ladder programs in mnemonics
Printing function blocks, block diagrams, etc.
1-8-2 Online Operations
Item
Connecting via serial communications
Downloading function block data
Downloading each ITEM's data
(Transferring to LC)
46
1.
Select the Step Ladder Program Block.
2.
Select Edit – Ladder Program from the Settings
Menu.
3.
Select the icon and move it onto the ladder
diagram and click the left mouse button.
4.
Double-click the left mouse button on the ladder
symbol. Input the data into the Data Setting Dialog
Box.
1.
Select the Step Ladder Program Block.
2.
Select Edit – Ladder Program from the Settings
Menu.
3.
Select Mnemonics from the Manipulate Ladder
Menu.
4.
Click the Insert Row Button.
5.
Input the instructions.
1.
Select Print from the File Menu, then select each
data type.
1.
Activate and select the folder of the function block file.
2.
Select Network Settings from the Settings Menu.
3.
Input the network address.
4.
Set the node address to 01.
5.
Select the LCU/LCB element (by default set to LC001-1).
6.
Select Network Settings from the Settings Menu.
7.
Input the unit address.
8.
Select Activate Serial Port Driver from the File Menu.
9.
Click the OK Button.
1.
Activate the folder of the function block file and select the
LCU/LCB element (default: LC001-1).
2.
Select Transfer to LC – Selected from the Execution
Menu.
When the version is different from the Loop Controller
element version, a warning dialog will be displayed. Click
the OK Button and continue.
3.
Click the OK Button.
4.
If a step ladder program is included, click the OK Button for
Convert Ladder To Mnemonics per LCU/LCB element.
5.
Click the OK Button.
6.
Set the objective item and start downloading the data.
1.
Select Monitor/ITEM List from the Execution Menu to
display the ITEM list, or double-click the function block
registered on the Project Workspace Screen.
2.
Double-click each ITEM.
3.
Set the desired value and click the Transfer to LC Button.
Menu item
Menu item
Section
1-8
Section
3-7-1
3-7-2
3-11
Section
4-2-2
4-3-1
4-3-1
