Omron CX-PROCESS TOOL V5.2 - REV 10-2010 Operation Manual page 57

Function Blocks/ITEMs Incompatible with Earlier Versions
ITEMs Incompatible with
Earlier Versions
1-5-5 Incompatibility with Versions Earlier than Version 3.2
Function Blocks
Incompatible with Earlier
Versions
The following ITEMs can be used only with version 2.50 or later versions of the
CS1W-LC001 Loop Control Unit and version 2.50 or higher versions of the CX-
Process Tool.
• Block Registration Flag (ITEM039) and Toolbar Version (ITEM110) in Sys-
tem Common (Block Model 000)
• Warning Limit (ITEM020) in the following Blocks:
Basic PID (Block Model 011), Advanced PID (Block Model 012), 2-position
ON/OFF (Block Model 001), 3-position ON/OFF (Block Model 002), In-
dication and Setting (Block Model 031), Indication and Operation (Block
Model 032), Ratio Setting (Block Model 033), Indicator (Block Model 034),
and 4-point Warning Indicator (Block Model 110)
• SP Rate-of-change Limit Time Unit (ITEM030) in Advanced PID (Block
Model 012)
• The following ITEMs in Batch Flowrate Capture (Block Model 014): Local
SP Setting, Upper 4 Digits (ITEM024), Remote SP Setting, Upper 4 Digits
(ITEM028), Current SP, Upper 4 Digits (ITEM030), Preset Value
(ITEM061), and Batch Accumulated Value, Upper 4 Digits (ITEM065)
• Time Units (ITEM013) in Rate-of-change Limiter (Speed Response)
(Block Model 143)
• Reference Input Disable Switch (ITEM020) in Segment Program 2 (Block
Model 157)
• Output Type (ITEM006) in Contact Distributor (Block Model 201)
• Individual I/O Range Settings in the following Blocks:
AI Terminal from CPU Unit (Block Model 453), AO Terminal from CPU Unit
(Block Model 454), AI4 Terminal (Block Model 561), PI4 Terminal (Block
Model 562), and AI8 Terminal (Block Model 564)
• Receive Stop Switch (ITEM225) in the following Blocks:
DI Terminal from Expanded CPU Unit (Block Model 455) and AI Terminal
from Expanded CPU Unit (Block Model 457)
• Send Stop Switch (ITEM225) in the following Blocks:
DO Terminal from Expanded CPU Unit (Block Model 456) and AO Termi-
nal from Expanded CPU Unit (Block Model 458)
Note 1. For details on which actual ITEM this restriction applies to, refer to the ITEM
list for the relevant function block in the Function Block Reference Manual.
2. The version of the Loop Control Unit can be verified in the Monitor Run Sta-
tus Screen (Execution, Operation, Monitor Run Status) on CX-Process
Tool.
When the above function blocks are used, check in the Check System Op-
eration screen on CX-Process Tool beforehand that the content of ITEM 099
onwards in the System Common block (Block Model 000) is as follows:
ITEM
099
The following function blocks can be used only with LCB01/LCB05 version 1.5 or
later, or LCB03, together with the CX-Process Tool version 3.20 or higher.
Ai4 Terminal (PTS51), Ai8 Terminal (PTS55), Ai4 Terminal (PTS52), Ai8
Terminal (PTS56), Ai8 Terminal (PDC55), Ao2 Terminal (DA021),
Ai4/Ao2 Terminal (MAD42)
Data name
MPU/FROM version indication V2.50
Version V2.50 and onwards must be indicated.
Section 1-5
Data
29
