Creating Function Block
Node is inserted automatically.
102
The Insert LCB/LC001 Dialog Box will be displayed.
The Number-Model (e.g., 00-LCB05) is set automatically
based on the Unit/Board model in the I/O Table Window.
When the CX-Process Tool is started by selecting Start with Settings In-
herited, the procedure up until the inserting the node's Function Block File is
performed automatically.
The project name is automatically created as follows:
Name: CXPrc + Year, month, day, hour, minute, and second that CX-Pro-
cess Tool was started (Example: CXPrc050207142030 when started 2005,
February 7 at 14:20:30.)
The folder in which the automatically-created project is saved will be the
same folder in which the CX-Programmer project is saved. If no CX-Pro-
grammer project has been saved, then "Desktop" will be selected.
Note When starting from the I/O tables, it is possible to select Start Only so that the
communications settings are not inherited. In that case, the starting method is
the same as when starting from the Windows Start Menu.
Section 3-1
