Creating User-defined Blocks

3-6-6 Importing User-defined Blocks from Files

The file type is ucb (file name extension: .ucb).
Open the project into which the user-defined block is to be imported, select the
LCB element, and select Settings – User-defined Block – Import. Specify a
file (.ucb), input a function block name for the user-defined block, and click the
Set Button. The block will be imported as shown below.
User-defined function block has been imported.
Note Only upward compatibility is ensured for exported user-defined block files.
Example:
• User-defined blocks created using LCBjj Ver. 3.0 cannot be imported to
projects using LCBjj Ver. 2.0.
• User-defined blocks created using LCBjj Ver. 1.5 can be imported to
projects using LCBjj Ver. 3.0.
Section 3-6
179
