User Link Tables
166
• Imported User Link Table
Data Imported from CX-Programmer Symbol Table
CX-Programmer local symbol table
Symbol name
Type yp
Address
R/W
Refresh cycle
Note The settings for the user link table will be saved automatically in an CSV format
file called LnkTable.csv in a folder with the same name as the project when the
project is saved. This file can be edited. The results of editing the file will be re-
flected in the user link table when the project is opened or when the active node
is switched.
CX-Process Tool user link table
→ Tag name
BOOL → Contact
CHANNEL → Analog
→ Memory type and memory address
(bit position)
→ Always Rd
Always 2 s
→
Section 3-5
