Omron CX-PROCESS TOOL V5.2 - REV 10-2010 Operation Manual page 228

Creating Sequence Tables
Signal Notation on
CX-Process Tool
screen
Write to SET(#value,
ITEM destination)
Types
Writing a constant
to a function block
ITEM write
parameter
Writing a constant
to an CSV tag and
tag ITEM (Contact
output ITEM for
control and
operation blocks)
User link table
(writing a constant
to I/O memory in
the CPU Unit)
Note The following output forms can be selected.
Settings on Setting method
CX-Process Tool
screen
ITEM Write tab Select the block
destination: Block ITEM, select the
ITEM ITEM number from
the detailed
information, and
input the write data
(–32,000 to
32,000).
ITEM Write tab Select the ITEM
destination: Tag tag, select the tag
name ITEM from the
detailed
information, and
input the write data
(–32,000 to
32,000).
ITEM Write tab Select the area
destination: User type, select the
link table user link table tag
from the detailed
information, and
input the write data
(–32,000 to
32,000: Input the
scaled value for
the user link table).
Section 3-8
Example
---
---
---
201
