Tuning
CSV File Format
Number of Records
Data Logging Cycle
296
Data is saved in the following format.
Function block
2-position ON/OFF (Block Model 001)
3-position ON/OFF (Block Model 002)
Basic PID (Block Model 011)
Advanced PID (Block Model 012)
Blended PID (Block Model 013)
Batch Flowrate Capture (Block Model 014)
Fuzzy Logic (Block Model 016)
Indication and Setting (Block Model 031)
Indication and Operation (Block Model 032)
Ratio Setting (Block Model 033)
Indicator (Block Model 034)
Segment Program 2 (Block Model 157)
When the maximum of 65,500 records is reached, the message will be displayed
and the Tuning Screen will be ended automatically.
The data logging cycle is 1 s or 200 ms. (Set 200 msec or 1 sec in the Tuning
Screen Setting Dialog Box.)
Note Setting the data logging cycle to 200 ms does not necessarily mean that the re-
fresh cycle will be 200 ms because the load on the computer and other factors
will affect it. Use this setting as a guideline only. If the refresh cycle is set to
200 ms, the multiple data for 1 second will be stored as one entry because the
CSV file format is for data every second.
Section
ITEMs output to CSV file as
logged data
PV, SP, MV
PV, SP, MVH, MVL
PV, SP, MV
PV, SP, MV
Y1, Y2, MV
Y1, MV
X1, X2, X3, X4, X5, X6, X7,
X8, Y1, Y2
PV, SP
PV, MV
PV, SP, MV
PV
X1, Y1
