Omron CX-PROCESS TOOL V5.2 - REV 10-2010 Operation Manual page 73

Operations
Item
Attaching user-defined comments (annotations) to
function blocks and step ladder diagrams,
displaying/printing comments
Settings tags for CX-Process Monitor (Loop
Control Unit only)
Compiling tags for Monitor Software (Loop
Control Unit only)
Checking tags for Monitor Software settings (Loop
Control Unit only)
Settings tags for CX-Process Monitor Plus
(CX-Process Tool Ver. 3.2 or higher)
Compiling tags for CX-Process Monitor Plus
(CX-Process Tool Ver. 3.2 or higher)
Checking tags for CX-Process Monitor Plus
settings
(CX-Process Tool Ver. 3.2 or higher)
Creating (compiling) the CSV tag file for SCADA
software
Creating (compiling) an RS View tag file (.csv)
Creating sequence tables (LCB05/05D only)
Menu item
In the Function Block Connection Diagram, click the
right mouse button to display the pop-up menu and
select Annotations/Insert.
Click the Annotation icon in Ladder Diagram Edit Mode.
1. Select the Send Terminal to Computer folder
(block models between 401 and 404) or the Send
Terminal to All Nodes (block models between 407
and 410).
2. Select Tag Settings – Monitor Tags from the
Settings Menu.
1. Select Create Tag File – Monitor Tags from the
Execution Menu.
2. Click the Start Button
1. Select Show Tag List – Monitor Tag from the
Execution Menu.
1. Select the function blocks and select Tag Settings
– CSV Tags from the Setting Menu, or select
function blocks for data exchange with the
CX-Process Monitor Plus and select Tag Settings
– Monitor Plus Tags from the Setting Menu.
or
Select the option to automatically register CSV
tags when registering function blocks and edit the
CSV tag file in Excel or other editor.
1. Select Create Tag File – Monitor Plus Tag from
the Execution Menu.
2. Click the Start Button on the main window of the
CX-Process Monitor Plus.
1. Select Show Tag List – Monitor Plus Tag from
the Execution Menu.
1. Select the function block and select Tag Settings
– CSV Tags from the Settings Menu to set the
CSV tags.
or
Select the option to automatically register CSV
tags when registering function blocks and edit the
CSV tag file in Excel or other editor.
2. Compile the CSV tag file by selecting Create Tag
File – CSV Tags from the Execution Menu.
1. Select the function block and select Tag Settings
– CSV Tags from the Settings Menu to set the
CSV tags.
or
Select the option to automatically register CSV
tags when registering function blocks and edit the
CSV tag file in Excel or other editor.
2. Compile the RS View tag file by selecting Create
Tag File – RS View Tags from the Execution
Menu.
1. Select the sequence table block.
2. Select Edit – Sequence Table from the Settings
Menu.
3. Right-click on the sequence table and select Edit
Mode – Enable.
4. Double-click the sequence table and input the data
into the Signal Dialog Box.
Section 1-8
Section
3-7-1
3-2-1
3-2-1
3-2-2
3-3
3-3
3-3
3-4-1
3-4-1
3-8-1
45
