Setting Segment Programs
Edit Window Functions
The following functions can be executed in the Edit Windows used for Segment Program settings.
Edit
Editing is possible by either selecting cells on the Edit Window and inputting parameters directly, or right-clicking
and selecting Edit from the pop-up menu.
• Press the Enter Key to move to a lower cell. When the cursor is in the bottom cell, it will next move to the to the cell
in the top row.
• Pressing the Esc Key during an input will cancel the input and restore the original value.
Undo
Used to undo an operation and restore edited data. A buffer is provided for up to 10 undo operations.
Note "Transfer to LC" operations cannot be undone.
Redo
Used to redo an action that was undone using the undo function.
Note "Transfer to LC" operations cannot be redone.
Copy and Paste
By right-clicking and selecting Copy from the pop-up menu, cell contents can be copied to the clipboard. The co-
pied data can then be pasted by clicking on a cell, right-clicking to display the pop-up menu, and selecting Paste.
• It is possible to select and copy multiple cells.
• Text data edited using an external editor can be pasted.
Fill
Used to copy data from a selected cell to all steps and set the same data for an entire line. Select a cell and then
right-click and select Fill from the pop-up menu.
Insert Columns
Used to insert step columns. Select all the data in the column to be inserted, and then right-click and select Insert
Columns from the pop-up menu.
• When multiple columns are selected, the selected number of columns can be inserted.
• Parameter default values are automatically input into inserted columns.
When new columns are inserted, an equivalent number of columns of step data is deleted from the last step col-
umns. The last step in a Segment Program 2 block is step 30, and the last step in a Segment Program 3 block is
step 100.
Delete Column
Used to delete step columns. Select all of the data in the column to be deleted, and then right-click and select
Delete Column from the pop-up menu. To select all of the column data, click the step number in the table.
• It is possible to select and delete multiple columns.
• When columns are deleted, an equivalent number of columns of step data is inserted from the last step column.
The last step in a Segment Program 2 block is step 30, and the last step in a Segment Program 3 block is step
100. The default values are set for all data in the newly inserted columns.
Move Column
Used to move step columns. Select all of the data in the column to be moved, and then right-click and select Move
Column from the pop-up menu. To select all of the column data, click the step number in the table.
When Move Column is selected, the cursor is changed to
• Multiple columns can be selected and moved.
. The column will move when selected in this state.
