Setting Options

3-12-2 General Tab Page

226
Project Workspace: Display by Tag name.
When this option is selected, CSV tag names will be displayed for function
blocks on the project tree whenever CSV tag names have been set.
When this option is not selected (the default), function block names will be dis-
played for function blocks on the project tree as normal.
Make the tag name registration default.
When this option is selected (the default), ITEMs can be specified from pull-
down lists of tag names and tag ITEM names for the following:
• For the source designation (connection data designation) for a function block
• When Edit – Edit Connection is selected after right-clicking an ITEM dis-
played in blue
• When editing signals in sequence tables
• When editing symbols in step ladder diagrams
Section 3-12
