Install A Profile From A Usb - Abbott i-STAT Alinity Operation Manual

• Previous to go back to the previous screen
• Discard to undo changes
• Finish Later to create a draft
• Publish to make the Profile available to use
The Profile Name list displays and now includes the Profile that was just created.
Save and Export a Profile
After a profile is published it can be saved and exported. To save a profile, on the Profile Name list, select
the check box next to the name of the profile to be saved. In the upper right corner of the screen, click
Export. At the bottom of the screen a prompt similar to the one shown below displays:
Select:
Open
Save
Cancel

Install a Profile from a USB

1. Ensure that the correct profile.apkg file has been loaded onto the USB.
2. Locate the USB port on the side of the Base Station and insert the USB.
3. Place the instrument on the Base Station. Power on the instrument.
4. Navigate to More Options > Administrative Options > Profile Management > Install Profile from USB
5. Follow the prompts on the screen to begin the installation process.
6. The Activate USB Drive screen displays 2 check boxes. Both boxes must display a green check mark
(✔) for the installation to proceed. If necessary, troubleshooting steps are listed below.
7. Confirm that the profile has been uploaded to the instrument by navigating to More Options >
Instrument Status then use Page key to advance to page 2. The profile name and date of install will
be displayed. If the correct information is not displayed, repeat the installation procedure.
Troubleshooting
If the instrument does not detect the Base Station, try the following:
• remove the instrument and re-seat it on the Base Station
• check to ensure the Base Station is getting power (blue light illuminated)
If the instrument does not detect the USB drive, try the following:
• remove the USB and reinsert
• make sure the USB is formatted
i-STAT Alinity — System Operations Manual
(Not recommended)
To save the file. Click the down arrow and select:
Save as
Save and open
To not save the file.
Art: 746300-01 Rev. N
To save the file to a specific
destination (USB).
(Not recommended)
Rev. Date: 02-Nov-2022
249
