Format
Entry Type
Scan Mask
i-STAT Alinity — System Operations Manual
Determine the format used to enter data. Select either:
Numeric Only
Alphanumeric
Determine how the data will be entered into the i‑STAT Alinity instrument. Select
one of the following:
Allow Scan and Manual Entry
Scan Only
Manual Entry Only
Minimum Length
Maximum Length
Barcode scanning setting that allows for the selection of specific character positions
to be retained.
• The first position (the position farthest to the left) is numbered position "1".
• The scanmask field will accept a text input consisting of numbers 1-9, commas
(','), and hyphens ('-') to identify the scanmask selection.
• If, for example, the barcode reads "abcdefghi1234567890" and the selection
pattern is "2,5-8,11-14" then the barcode will be interpreted as "befgh2345". If
the selection pattern is "3-4", then the barcode will be "cd".
• Individual position selections that are separated by a comma such as
"2,4,7,8,19" cannot be duplicated.
• In each number range, the starting number must be smaller than the ending
number. For example, "3-5" is a valid range, but "5-3" is not.
• Selection ranges cannot overlap. The end of each number range must be smaller
than the beginning of the next number range. For example, "3-6,7-9" is a valid
selection, but "3-6,6-9" is not.
• Entering consecutive commas or hyphens is invalid. For example, "2--5",
"2-5,,7-10", and "2,-5" are all invalid ranges.
Data will be entered only as numbers.
Data will be entered as either letters or
numbers.
Allow barcode scan or manual data entry.
Allow barcode scan data entry only.
Allow manual data entry only.
Enter the minimum data characters
allowed.
Enter the maximum data characters
allowed.
