AlinIQ NCi - Wired Network Connection

Specify the following information for connectivity to a wired network:
I want the i‑STAT Alinity to connect to my facility's WIRED network
To configure connectivity for a wired network, select this check box and specify values for:
Authentication Type
OPEN (this value is not modifiable)
IP Address Mode
Select one of these values:
• Automatic (DHCP) - Obtain IP addresses and networking parameters automatically from a
DHCP server.
• Use the following IP Address - Select this button to use a static IP address.
IP Address
IPv4 address of instrument in decimal dot notation.
i-STAT Alinity — System Operations Manual
Note: If you specify a static IP address you must also specify DNS addresses.
