Transition Type

You can set the way in which the transition occurs.
The transition type is configured using the transition
control block, simple-type transition type control block,
or the menu.
For details about transition types, see "Transition type"
(page 95).

Setting a Transition Type

Setting a transition type (transition
control block)
You can select a transition type using the transition
control block/transition control block (simple type) of the
target switcher bank.
Notes
• The buttons used for configuring the transition type
must be assigned to the transition control block/
transition control block (simple type) beforehand.
For details about assigning buttons, see "Assigning
Control Panel Buttons" (page 402).
• When the operation mode of the switcher bank is set to
multi program mode or multi program 2 mode, preset
color mix cannot be used when selecting a key for a
next transition.
• When the operation mode of the switcher bank is set to
multi program mode or multi program 2 mode, there
may be cases in which two or more transition type
selection buttons are lit.
1
Select a transition type using the transition type
selection buttons.
Press the [MIX] button, [NAM] button, [SUPER
MIX] button, [PST COLOR MIX] button, [WIPE]
button, [DME WIPE] button, or a [FM1&2 CLIP] to
[FM15&16 CLIP] button, turning it on.
2
Set the transition type.
Make the required settings for the selected transition
type.
When a mix, non-additive mix, super mix, preset
color mix, wipe, or DME wipe is selected
Set the transition rate.
For details about the transition rate, see "Transition
Rate" (page 101).
When super mix is selected
Set the output level at the mid-point of the transition.
For details, see "Setting Super Mix" (page 100).
When preset color mix is selected
Set the color matte to insert during the transition.
For details, see "Setting a Preset Color Mix"
(page 100).
When a wipe is selected
Set the wipe pattern.
For details, see "Setting a Wipe" (page 149).
When a DME wipe is selected
Set the DME wipe pattern.
For details, see "Setting a DME Wipe" (page 165).
When a clip transition is selected
Set the clip transition.
For details, see "Setting a Clip Transition"
(page 173).
Setting the key transition type (menu)
This section describes the M/E-1 menu as an example.
1
Open the Home > M/E-1 > Bus/Transition >
Transition > Transition Type menu (11109.21).
2
Select a transition type in the [Transition Type]
group.
Mix: Mix
NAM: Non-additive mix
Super Mix: Super mix
Preset Color Mix: Preset color mix
Wipe: Wipe
DME Wipe: DME wipe
FM 1&2 Clip to FM 15&16 Clip: Clip transition
3
Set the transition type.
Make the required settings for the selected transition
type.
When a mix, non-additive mix, super mix, preset
color mix, wipe, or DME wipe is selected
Set the transition rate.
For details about the transition rate, see "Transition
Rate" (page 101).
When super mix is selected
Set the output level at the mid-point of the transition.
For details, see "Setting Super Mix" (page 100).
When preset color mix is selected
Set the color matte to insert during the transition.
