Function name Button
name
Others: PRE MCRO Sets macro attachment
Pre Macro
Others: POST
Post Macro MCRO
Others: MCRO
Macro Attach ATTCH
Enable ENBL
Others: MAIN
Main
Others: SUB
Sub
Others: DISP
Display Mode MODE
Others: AUX MIX
a) b)
Row-n Aux Mix
Others: AUX MIX
b) f)
Aux Mix
Others: KEY
a) b)
Row-n Key
Others: KEY
b) f)
Key
Others: IMAGE
Row-n Image
g) h)
Effect
Others: PROT
e)
Row-n Protect
Others: UTIL
a) f)
Utility
Others: SHIFT ALL
Shift All Bus
Others: DUAL
f)
Dual BKGD Bus BKGD BUS
Others: INHBT SET Sets/releases inhibit
Xpt Inhibit
Description
in pre-macro mode.
Sets macro attachment
in post-macro mode.
Enables macro
attachments assigned
to buttons in the
switcher banks.
Switches the button
operation to the
function on the main
side when in multi
program 2 mode.
Switches the button
operation to the
function on the sub side
when in multi program 2
mode.
Switches the display
mode.
Executes an AUX mix
when an AUX bus is
assigned to the 1st row
to 4th row.
n = 1 to 4
Executes an AUX mix
when an AUX bus is
assigned to the 2nd
row.
Selects the signal on
the key side in the 1st
row to 4th row.
n = 1 to 4
Selects the signal on
the key side in the 2nd
row.
Sets the image effect
function on background
A bus or B bus on the
1st row to 4th row.
n = 1 to 4
Inhibits button
operation on the 1st
row to 4th row.
n = 1 to 4
Assigns the bus when
in utility bus mode to
the 1st row to 4th row.
Switches the cross-
point button rows of all
buses to the shifted
state.
Switches to dual
background bus mode.
mode for cross-point
buttons.
49
Function name Button
name
Others: INHBT
Xpt Inhibit All Clear ALLCLR
a) Disabled in key/AUX bus delegation mode.
b) Disabled in key bus mode.
c) 3rd row and 4th row are disabled in key bus mode.
d) Disabled for SL keys.
e) 1st row is disabled in key/AUX bus delegation mode.
f) Disabled in free assign mode.
g) 1st row and 2nd row are disabled in key bus mode.
h) 1st row and 2nd row are disabled in key/AUX bus delegation mode.
Description
Releases inhibit mode
for all cross-point
buttons.
