3
Enable/disable recueing using the [Recue] button.
On: Enable recueing. After playing the loaded file,
recue the beginning and then stop.
Off: Disable recueing.

Setting a Disk Recorder (Odetics)

1
Open the Home > Setup > External Device > Serial/
Net Port Setting > DDR Odetics menu (19105.64).
A list of ports is shown on the left and the settings
status of the selected port is shown on the right.
2
In the list on the left, select the target port to set.
3
In the [TC Sense] group, select a timecode sense
mode.
Zero based: Timecode sense (detection), taking the
first frame of the loaded file as 00:00:00:00.
SOM based: Sense (detection) occurs using the
timecode recorded in the loaded file.
4
In the list on the right, set the response speed of the
item.
Press the [Setting] button for an item to set and enter
a setting in the numeric keypad window.
Item Item description
Maximum Maximum time required to open a file
Open Delay
Maximum Maximum time required to cueup a
Cueup Delay file
Play After Delay time after cueup until playback
Cueup Delay starts
Stop Delay Delay time from issuing the Stop
command until playback stops
Still Delay Delay time from issuing the Still
command until playback stops
Command Delay time from issuing the Auto
Delay (Auto Mode On/Off command until the
Mode) command takes effect
Command Delay time from issuing the Out
Delay (Out Preset command until the command
Preset) takes effect
Command Delay time from issuing the Preview
Delay (Preview In Preset command until the
In Preset) command takes effect
Internal Reserved for future use.
Parameter (1) Set the value to "255".
to (4)

Setting an AMP Compatible Device

1
Open the Home > Setup > External Device > Serial/
Net Port Setting > AMP menu (19105.65).
A list of ports is shown on the left and the settings
status of the selected port is shown on the right.
2
In the list on the left, select the target port to set.
3
Press the [IP Address] button and enter an IP address
using the keyboard.
4
Press the [TCP/IP Port] button and enter a port
number in the numeric keypad window.
5
In the [TC Sense] group, select a timecode sense
mode.
Zero based: Timecode sense (detection), taking the
first frame of the loaded file as 00:00:00:00.
SOM based: Sense (detection) occurs using the
timecode recorded in the loaded file.
6
In the list on the right, set the video port and response
speed of the item.
Press the [Setting] button for an item to set and enter
a setting in the numeric keypad window.
Item
Video Port
Maximum
Open Delay
Maximum
Cueup Delay
Play After
Cueup Delay
Stop Delay
Still Delay
Command
Delay (Auto
Mode)
Command
Delay (Out
Preset)
Command
Delay (Preview
In Preset)
Internal
Parameter (1)
to (3)
431
Item description
Number of the video port (1 to 4)
associated with the target port to set
Maximum time required to open a file
Maximum time required to cueup a
file
Delay time after cueup until playback
starts
Delay time from issuing the Stop
command until playback stops
Delay time from issuing the Still
command until playback stops
Delay time from issuing the Auto
Mode On/Off command until the
command takes effect
Delay time from issuing the Out
Preset command until the command
takes effect
Delay time from issuing the Preview
In Preset command until the
command takes effect
Reserved for future use.
Set the value to "255".
