Interroll Module belt conveyor SH 1100
Maintenance and repair

Preparatory and follow-up maintenance work

DANGER
Danger to life from electrocution and crushing
Installation and maintenance tasks on 400-V conveyor systems while they are in operation can
cause life-threatening electrocution and serious crushing.
4 Power down the entire conveyor module and ensure that it cannot be started accidentally.
The following preparatory and follow-up maintenance work can be performed at the straight
module belt conveyor:
• Remove cover plates at return axles, see "Removing/installing cover plates at return axles",
page 52
• Remove contact guard and covers at center drive station, see "Removing/installing contact
guard and covers at center drive station", page 53
• Remove cable connection cover of head drive, see "Removing/installing head drive cable
connection cover", page 54
• Remove cable connection cover of center drive, see "Removing/installing center drive cable
connection cover", page 54
• Remove end plates at idler axles, see "Removing/installing front side idler axle end plate",
page 56
