Interroll Module belt conveyor SH 1100
Installation
Integrating the module in a complete system
CAUTION
Risk of crushing and injuries from cuts
4 When integrating the module into a complete system, consider possible danger spots,
particularly infeed locations and interfaces.
The module is delivered pre-assembled, but integration into a complete system may still require
individual installation tasks:
• Install the universal support, see "Installing the universal support", page 23.
• Fasten the side guide, see "Installing the side guide", page 25.
• Install photo cell and reflector, see "Installing the photo cell and reflector", page 26.
• Attach the module connectors and contact guards, see "Connecting the modules", page 29.
Integrating the module in a complete system may require installing other components. The
corresponding instructions are available in the chapter "Maintenance and Repair".
Version 1.0 (06/2022) en
Translation of original operating instructions
