Interroll Module belt conveyor SH 1100
Product identification
Rated width (BF)
Conveying width (CW)
Dimensions of conveying good
Max. load capacity
Conveyor speed
Ambient temperature
Incline/decline
Angle adjustability
Max. module length
Conveying height (TOB)
Number of zones (N)
Motor type
Rated voltage
Electrical power
Drive system
Transmission of force
Frequency inverter
Module conveyor
Side frame hole spacing
Reversibility
Protection rating
SH 1100 CD
405 mm (S)
710 mm (M)
862 mm (L)
Min.: 100 x 100 mm
Max.: 700 x 800 mm
35 kg/m
0.1 to 0.8 m/s
–5 to +40 °C
-6 to -18°; +6 to +18°
In increments of 3°
Preselected in the layouter
Preselected in the layouter
1
Synchronous/asynchronous drum motor
DM 0080, DM 0113, DM 0138, DM 0165
230/400 V 50 Hz
230/460 V 60 Hz
550 to 1818 W
Center drive (CD)
Sprockets
Standard: Getriebebau Nord
Ammeraal M-QNB-C
90 mm
Yes
Drum motor: IP 69 K
Frequency inverter: IP 20 or IP 66
