Technical data

Version 1.0 (06/2022) en
Translation of original operating instructions
Interroll Module belt conveyor SH 1100
Product identification
Rated width (BF)
Conveying width (CW)
Dimensions of conveying good
Max. load capacity
Conveyor speed
Ambient temperature
Incline/decline
Angle adjustability
Max. module length
Conveying height (TOB)
Number of zones (N)
Motor type
Rated voltage
Electrical power
Drive system
Transmission of force
Frequency inverter
Module conveyor
Side frame hole spacing
Reversibility
Protection rating
SH 1100 HD
405 mm (S)
710 mm (M)
862 mm (L)
Min.: 100 x 100 mm
Max.: 700 x 800 mm
35 kg/m
0.1 to 0.8 m/s
–5 to +40 °C
-6 to -18°; +6 to +18°
In increments of 3°
Preselected in the layouter
Preselected in the layouter
1
Synchronous drum motor DM 0080
230/400 V 50 Hz
230/460 V 60 Hz
550 W
Head drive (HD)
Sprockets
Standard: Getriebebau Nord
Ammeraal M-QNB-C
90 mm
No
Drum motor: IP 69 K
Frequency inverter: IP 20 or IP 66
15
