About this Chapter
Configuring the HP E1415
Chapter 1
This chapter will explain hardware configuration before installation in a
VXIbus mainframe. By attending to each of these configuration items, your
HP E1415 won't have to be removed from its mainframe later. Chapter
contents include:
•
Configuring the HP E1415 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
•
Instrument Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
•
About Example Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
•
Verifying a Successful Configuration . . . . . . . . . . . . . . . . . . . . . . . 27
There are several aspects to configuring the module before installing it in a
VXIbus mainframe. They are:
•
Setting the Logical Address Switch . . . . . . . . . . . . . . . . . . . . . . . . 20
•
Installing Signal Conditioning Plug-ons . . . . . . . . . . . . . . . . . . . . . 21
•
Disabling the Input Protect Feature (optional) . . . . . . . . . . . . . . . . 25
•
Disabling Flash Memory Access (optional) . . . . . . . . . . . . . . . . . . 25
For most applications you will only need to change the Logical Address
switch prior to installation. The other settings can be used as delivered.
Note
Setting the VXIbus Interrupt Level: The HP E1415 uses a default VXIbus
interrupt level of 1. The default setting is made at power-on and after a
*RST command. You can change the interrupt level by executing the
DIAGnostic:INTerrupt[:LINe] command in your application program.
Getting Started
Switch/Jumper
Logical Address Switch
Input Protect Jumper
Flash Memory Protect Jumper
Chapter 1
Setting
208
Protected
PROG
Getting Started
19
