Digital Pulse Counter option definitions

The following table provides Remote Manager definitions for Digi Connect Sensor+ Digital: Pulse Counter options. For additional information about using
these options, see Enable and configure a digital pulse
Option Description
Interface Enable Enables or disables the digital input source.
High Alarm Enables or disables high alarm reports for the digital pulse counter.
Specifies the number of pulses that generates a high alarm report when High Alarm is On.
High Threshold
Low Alarm Enables or disables low alarm reports for the digital pulse counter source.
Specifies the number of pulses that generates a low alarm report when Low Alarm is On.
Low Threshold
Specifies when to keep an alarm on or shut off an alarm during high and low alarm states.
Hysteresis
0 — hysteresis is off
1 or more — hysteresis is on and managing alarms
Enable pullup Enables or disables the internal pull-up resistor to drive a logic level voltage.
Sensor Specifies description of the sensor for the pulse counter.
description
Custom Scaled Specifies the unit of measurement the pulse counter uses for the custom scaled sensor values.
Sample Unit
Specifies the number used to convert each pulse into the custom scaled sample unit. For example, if one
Custom Scaling
pulse equals 0.011 inches, you would enter 0.011 in this field.
Factor
counter.
Range
Default
On/Off Off
On/Off Off
Number 0
On/Off Off
Number 0
Number 0
On/Off Off
Text Empty
Text Empty
Number 0
