Hardware
1. Press the Wake button inside the device or swipe a magnet across the device.
2. The cellular and battery LEDs light up purple for one second and then turn off.
3. The sensor LED blinks green as readings are taken and then turns off when readings are
complete.
4. If Bluetooth is enabled, the Bluetooth LED blinks yellow for 30 seconds. If a Bluetooth device is
attached, the Bluetooth LED turns solid and remains lit.
Note If Bluetooth is not enabled, the Bluetooth LED does not light up.
5. Digi Connect Sensor+ takes and pushes data readings.
a. The Digi Connect Sensor+ takes a battery life reading. The battery LED blinks either
b. The cellular LED blinks blue until the connection to Remote Manager is complete.
c. The Digi Connect Sensor+ pushes the data. When the data transfer is complete, the
d. After a few seconds, the cellular LED turns off.
CLI commands and waking Digi Connect Sensor+
You can connect a USB cable from a computer to Digi Connect Sensor+ and use CLI commands to
perform actions on the device.
Digi Connect Sensor+ has a 30-second timeout period between when a CLI command has been
entered and the command is processed. When Digi Connect Sensor+ has finished processing the
command, the device goes to sleep, and "zzz... " appears in the terminal program.
If you press the Wake button or use a magnet to wake Digi Connect Sensor+ during this 30-second
timeout period, the LED lights will not be activated, as the device is already awake. Make sure "zzz..."
appears in the terminal program before you try to wake the device.
See Open a terminal program and use CLI commands

Install the magnet mount

You can install a magnet mount on Digi Connect Sensor+ so that you can securely place the device on
a metal object.
Make sure you have the following equipment available:
Magnet mount accessory pack. See
n
information.
Appropriate screw driver.
n
Note You can skip this step if you did not purchase the magnet mount accessory pack.
1. Turn Digi Connect Sensor+ to access the bottom of the device.
2. Remove one magnet from the set of four magnets in the accessory pack.
Digi Connect Sensor+ User Guide
blue or red, depending on the status of the battery life.
cellular LED is solid blue.
Step 1: Verify product components
Install the magnet mount
for more details about this process.
for purchasing
