Configure pins and protocols
7. Select the appropriate Output Level for your digital output. Refer to the manufacturer
specifications for the sensor.
8. Select the appropriate Toggle Output on option If you want to toggle the digital output on a
selected alarm. For more detailed information, see
9. Select On for Enable pullup when your application requires it.
10. Enter a user-friendly name for the sensor in the Sensor Description field.
11. Apply the configuration changes:
a. Click Save > Schedule. The Save Device Properties dialog appears.
b. Select Immediate.
c. Select Schedule Offline.
d. Click Schedule. Digi Connect Sensor+ downloads and applies configuration changes

Enable and configure a digital power output

Note Powering sensors reduces battery life.
Configure the digital power output options when you use Digi Connect Sensor+ to power an external
device. For details about the configuration options, see
Output option definitions.
To set digital power output options in Remote Manager:
1. Sign in to Remote
2. Click the arrow next to your user name and choose Open Classic Remote Manager.
3. Click Device Management > Devices tab.
4. Double-click the Digi Connect Sensor+ device you want to configure.
5. Expand the Configuration menu.
5. Select Digital: Power Output.
6. Enable the output by selecting On for Power Output Enable.
7. Select the appropriate voltage Output Level for your power output. Refer to the manufacturer
specifications for the sensor.
8. Enter the appropriate Read Delay that your sensor needs to stabilize before reading the
sensor input value. Refer to the manufacturer specifications for the sensor.
For example, a sensor may need 7 seconds to power on and stabilize before it can get an
accurate reading.
Note A higher read delay keeps the device powered on longer, which reduces battery life.
9. Apply the configuration changes:
Digi Connect Sensor+ User Guide
the next time it connects to Remote Manager.
Manager.
Enable and configure a digital power output
Toggle digital output on
Analog Power, Digital Power, and Serial
alarm.
