Firmware updates
a. Click Save > Schedule. The Save Device Properties dialog appears.
b. Select Immediate.
c. Select Schedule Offline.
d. Click Schedule. Digi Connect Sensor+ downloads and applies configuration changes
6. Configure the buffer time for the sensor to ensure the desired amount of data is stored when
an alarm occurs. For information, see

Enable continuous monitoring on analog input

Note The Digi Connect Sensor+ firmware must be upgraded before continuous monitoring can be
enabled on the analog or digital input. For information, see
1. Follow the standard process to configure an Analog 4-20mA Current Loop or Analog Voltage
Input. For instructions, see
2. The analog input must be enabled. Verify that the Interface Enable (ena) option is set to On.
3. Verify that the Continuous Monitoring Enable (mon) option is set to On.
4. Click Save.
5. Apply the configuration changes:
a. Click Save > Schedule. The Save Device Properties dialog appears.
b. Select Immediate.
c. Select Schedule Offline.
d. Click Schedule. Digi Connect Sensor+ downloads and applies configuration changes
6. Configure the buffer time for the sensor to ensure the desired amount of data is stored when
an alarm occurs. For information, see

Configure the buffer time for continuous monitoring

To ensure the desired amount of data is stored when an alarm occurs, you should configure the buffer
time range for the sensor.
1. Sign in to Remote
2. Click your user name and select Open Classic Remote Manager.
3. Click Device Management > Devices.
4. Double-click on the Digi Connect Sensor+ device you want to configure.
5. Expand the Configuration menu.
6. Click Device Settings.
Digi Connect Sensor+ User Guide
the next time it connects to Remote Manager.
Enable and configure analog
the next time it connects to Remote Manager.
Manager.
CSENSE Continuous Monitoring firmware
Configure the buffer time for continuous
CSENSE Continuous Monitoring
inputs.
Configure the buffer time for continuous
monitoring.
firmware.
monitoring.
