3-8-4-1 External I/O Pin Outs (cont'd)
Table 3-16
Pin No
1
2
3
4
5
6
7
8
9
10
11
12
3-8-5

Video Specification

Video specifications may be needed to be able to connect laser cameras or other devices to the Voluson
E8 / Voluson E6.
DVI-D/VGA-Connector:
-
-
S-Video Connector:
-
-
Section 3-9

Available Probes

See Chapter 9 - Probes, on page
service probes.
Section 3-10

Software/Option Configuration

For description refer to:
• Section 3-8-1 "System Setup" on page 3-49
• Section 3-8-2 "Measure Setup" on page 3-53
NOTICE
More detailed information pertaining System Setup and Measure Setup adjustments is found in the
Voluson E8 / Voluson E6 Basic User Manual, which is available in different languages.
!! NOTICE:
3-58
7 DRAFT (A
EVISION
DVI-D OUT Connector
Description
TDMS data 2-
TDMS data 2+
TDMS data 2, 4 shielding
TDMS data 4-
TDMS data 4+
DDC clock
DDC data
Analog: V-Sync
TDMS data 1-
TDMS data 1+
TMDS data 1, 3 shielding
TDMS data 3-
Visible resolution ... 1024x768
Screen refresh rate ... 60Hz
Type: Separate Video (Y/C)
Video modes: PAL (50Hz), NTSC (60Hz)
9-39, for part numbers to be used when ordering new or replacement
Section 3-9 - Available Probes
23, 2012)
UGUST
Pin No
13
14
15
16
17
18
19
20
21
22
23
24
and
V E8 / V
OLUSON OLUSON
S
ERVICE
Description
TDMS data 3+
+5 Volt
ground for +5 Volt
Hotplug-Detect
TDMS data 0-
TDMS data 0+
TDMS data 0, 5 shielding
TDMS data 5-
TDMS data 5+
TDMS meter shielding
TDMS clock +
TDMS clock -
