6. Software
These files are available
URmagic log file
URmagic backup programs
URmagic configuration files
URmagic upload programs
URmagic screenshot
Go to www.universal-robots.com/support/
Instruction for using Magic files.
1. Download Magic file.
2. Save it in the root folder on a USB-stick.
If more than one Magic file is on USB-stick, they will be run in sequence; the warnings will
then appear for each file. Do not remove the USB-stick until after the last file has been run.
Multiple folders will be created and named with serial number plus a sequential no, e.g.
201430xxxx_0, 201430xxxx_1etc.
3. Insert USB-stick into USB-connector on right-hand side of teach pendant.
4. After a few seconds a red
remove the USB-stick, while the file will do its magic.
5. Await a green
the USB-stick then go to step 4.
6. After the last Magic file is completed the USB-stick can be safely removed.
7. Remove USB-stick and the process is complete.
The Magic file creates a folder on USB-stick named with the serial number of the robot.

6.4. Backup of data

NOTICE
When copying/moving files and folders, incorrect action might corrupt the file
system.
This section explains the process of moving required files when upgrading from motherboard
with compact flashcard to motherboard with USB.

6.4.1. Hardware Requirements

Compact Flash Card from the old motherboard
A standard flash card reader that can read the CF-card (not included in motherboard upgrade kit).
User Manual
! USB ! -sign will appear on the screen, this is a warning not to
<- USB -sign appears on the screen, if there is more than one Magic file on
Function
Copies the entire log history file to USB-stick
Copies all programs and installation files to
USB-stick
Copies all configuration files to USB-stick
Copies all programs and installation files from
USB-stick
Generates a screenshot of GUI when USB-stick
is inserted
to download Magic files.
85 UR5
