Analog I/O Option Mcb - Danfoss VLT AQUA Drive FC 200 Programming Manual

Parameter Lists

4.1.23 26-** Analog I/O Option MCB 109

Par. No. #
26-0* Analog I/O Mode
26-00
26-01
4 4
26-02
26-1* Analog Input X42/1
26-10
26-11
26-14
26-15
26-16
26-17
26-2* Analog Input X42/3
26-20
26-21
26-24
26-25
26-26
26-27
26-3* Analog Input X42/5
26-30
26-31
26-34
26-35
26-36
26-37
26-4* Analog Out X42/7
26-40
26-41
26-42
26-43
26-44
26-5* Analog Out X42/9
26-50
26-51
26-52
26-53
26-54
26-6* Analog Out X42/11
26-60
26-61
26-62
26-63
26-64
Table 4.27
218
Parameter description
Terminal X42/1 Mode
Terminal X42/3 Mode
Terminal X42/5 Mode
Terminal X42/1 Low Voltage
Terminal X42/1 High Voltage
Term. X42/1 Low Ref./Feedb. Value
Term. X42/1 High Ref./Feedb. Value
Term. X42/1 Filter Time Constant
Term. X42/1 Live Zero
Terminal X42/3 Low Voltage
Terminal X42/3 High Voltage
Term. X42/3 Low Ref./Feedb. Value
Term. X42/3 High Ref./Feedb. Value
Term. X42/3 Filter Time Constant
Term. X42/3 Live Zero
Terminal X42/5 Low Voltage
Terminal X42/5 High Voltage
Term. X42/5 Low Ref./Feedb. Value
Term. X42/5 High Ref./Feedb. Value
Term. X42/5 Filter Time Constant
Term. X42/5 Live Zero
Terminal X42/7 Output
Terminal X42/7 Min. Scale
Terminal X42/7 Max. Scale
Terminal X42/7 Bus Control
Terminal X42/7 Timeout Preset
Terminal X42/9 Output
Terminal X42/9 Min. Scale
Terminal X42/9 Max. Scale
Terminal X42/9 Bus Control
Terminal X42/9 Timeout Preset
Terminal X42/11 Output
Terminal X42/11 Min. Scale
Terminal X42/11 Max. Scale
Terminal X42/11 Bus Control
Terminal X42/11 Timeout Preset
MG20O602 - VLT
®
VLT AQUA Drive Programming Guide
Default value
[1] Voltage
[1] Voltage
[1] Voltage
0.07 V
10.00 V
0.000 N/A
100.000 N/A
0.001 s
[1] Enabled
0.07 V
10.00 V
0.000 N/A
100.000 N/A
0.001 s
[1] Enabled
0.07 V
10.00 V
0.000 N/A
100.000 N/A
0.001 s
[1] Enabled
[0] No operation
0.00 %
100.00 %
0.00 %
0.00 %
[0] No operation
0.00 %
100.00 %
0.00 %
0.00 %
[0] No operation
0.00 %
100.00 %
0.00 %
0.00 %
®
is a registered Danfoss trademark
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
Type
- Uint8
- Uint8
- Uint8
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
