Parameter Description
10-32 Devicenet Revision
Range: Function:
Size related [0 - 65535 ] View the DeviceNet revision number.
*
This parameter is used for EDS file
creation.
10-33 Store Always
Option: Function:
[0] Off Deactivates non-volatile storage of data.
[1] On Stores parameter data received via DeviceNet in
EEPROM non-volatile memory as default.
10-34 DeviceNet Product Code
Range:
Size related [0 - 65535 ]
*
10-39 Devicenet F Parameters
Array [1000]
No LCP access
Range: Function:
0 [0 - 0 ] This parameter is used to configure the frequency
*
converter via DeviceNet and build the EDS-file.
3.11.5 10-5* CANopen
10-50 Process Data Config Write.
Option:
[0] None
*
[302] Minimum Reference
[303] Maximum Reference
[312] Catch up/slow Down Value
[341] Ramp 1 Ramp up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp up Time
[352] Ramp 2 Ramp down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[411] Motor Speed Low Limit [RPM]
[412] Motor Speed Low Limit [Hz]
[413] Motor Speed High Limit [RPM]
[414] Motor Speed High Limit [Hz]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[590] Digital & Relay Bus Control
[593] Pulse Out #27 Bus Control
[595] Pulse Out #29 Bus Control
[597] Pulse Out #X30/6 Bus Control
[653] Terminal 42 Output Bus Control
[663] Terminal X30/8 Bus Control
[673] Terminal X45/1 Bus Control
[683] Terminal X45/3 Bus Control
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
®
VLT AQUA Drive Programming Guide
10-50 Process Data Config Write.
Option:
[1293]
[1680]
[1682]
[3401]
[3402]
[3403]
[3404]
[3405]
[3406]
[3407]
[3408]
[3409]
Function:
[3410]
10-51 Process Data Config Read.
Option:
[0]
[1472]
[1473]
[1474]
[1500]
[1501]
[1502]
[1600]
[1601]
[1602]
Function:
[1603]
[1605]
[1609]
[1610]
[1611]
[1612]
[1613]
[1614]
[1615]
[1616]
[1617]
[1618]
[1619]
[1620]
[1622]
[1625]
[1630]
[1632]
[1633]
[1634]
[1635]
[1638]
[1639]
[1650]
[1651]
[1652]
®
MG20O602 - VLT is a registered Danfoss trademark
Cable Error Length
Fieldbus CTW 1
Fieldbus REF 1
PCD 1 Write to MCO
PCD 2 Write to MCO
PCD 3 Write to MCO
PCD 4 Write to MCO
PCD 5 Write to MCO
PCD 6 Write to MCO
PCD 7 Write to MCO
PCD 8 Write to MCO
PCD 9 Write to MCO
PCD 10 Write to MCO
None
*
VLT Alarm Word
VLT Warning Word
VLT Ext. Status Word
Operating Hours
Running Hours
kWh Counter
Control Word
Reference [Unit]
Reference %
Status Word
Main Actual Value [%]
Custom Readout
Power [kW]
Power [hp]
Motor Voltage
Frequency
Motor Current
Frequency [%]
Torque [Nm]
Speed [RPM]
Motor Thermal
KTY sensor temperature
Motor Angle
Torque [%]
Torque [Nm] High
DC Link Voltage
Brake Energy /s
Brake Energy /2 min
Heatsink Temp.
Inverter Thermal
SL Controller State
Control Card Temp.
External Reference
Pulse Reference
Feedback [Unit]
Function:
