Parameter Description
8-31 Address
Range:
Size related
*
3 3
8-32 Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
*
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
Default refers to the FC Protocol.
8-33 Parity / Stop Bits
Option:
[0] Even Parity, 1 Stop Bit
*
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-35 Minimum Response Delay
Range:
Size related
*
ms]
8-36 Max Response Delay
Range:
Size related
*
ms]
8-37 Maximum Inter-Char Delay
Range:
Size related
*
ms]
86
Function:
[ 0 - 126. ] Enter the address for the FC (standard)
port.
Valid range: 1-126.
Function:
Baud rates 9600, 19200, 38400 and 76800
baud are valid for BACnet only.
Function:
Parity and Stop Bits for the protocol
8-30 Protocol using the FC Port. For
some of the protocols, not all
options are visible. Default depends
on the protocol selected.
Function:
[ 0 - 10000. Specify the minimum delay time
between receiving a request and
transmitting a response. This is
used for overcoming modem
turnaround delays.
Function:
[ 11. - 10001. Specify the maximum permissible
delay time between transmitting a
request and receiving a response.
Exceeding this delay time will cause
control word time-out.
Function:
[ 0.00 - 35.01 Specify the maximum permissible
time interval between receipt of
two bytes. This parameter activates
MG20O602 - VLT
®
VLT AQUA Drive Programming Guide
8-37 Maximum Inter-Char Delay
Range:
3.9.4 8-4* Telegram Selection
8-40 Telegram Selection
Option:
[1] Standard telegram 1
*
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
[202] Custom telegram 3
8-42 PCD Write Configuration
Option:
[0]
[302]
[303]
[341]
[342]
[351]
[352]
[380]
[381]
[411]
[413]
[416]
[417]
[590]
[593]
®
is a registered Danfoss trademark
Function:
time-out if transmission is
interrupted.
Function:
Enables use of freely configurable
telegrams or standard telegrams for
the FC port.
None
Minimum Reference
Maximum Reference
Ramp 1 Ramp Up Time
Ramp 1 Ramp Down Time
Ramp 2 Ramp Up Time
Ramp 2 Ramp Down Time
Jog Ramp Time
Quick Stop Ramp Time
Motor Speed Low Limit [RPM]
Motor Speed High Limit [RPM]
Torque Limit Motor Mode
Torque Limit Generator Mode
Digital & Relay Bus Control
Pulse Out #27 Bus Control
Function:
Select the
parameters to be
assigned to PCD's
telegrams. The
number of available
PCDs depends on
the telegram type.
The values in PCD's
will then be written
to the selected
parameters as data
values.
