Load/Motor - Danfoss VLT AQUA Drive FC 200 Programming Manual

Parameter Lists

4.1.3 1-** Load/Motor

Par. No. Parameter description
#
1-0* General Settings
1-00 Configuration Mode
1-01 Motor Control Principle
1-03 Torque Characteristics
1-06 Clockwise Direction
1-1* Motor Selection
1-10 Motor Construction
1-1* VVC+ PM
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-2* Motor Data
1-20 Motor Power [kW]
1-21 Motor Power [HP]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-28 Motor Rotation Check
1-29 Automatic Motor Adaptation (AMA)
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs)
1-31 Rotor Resistance (Rr)
1-33 Stator Leakage Reactance (X1)
1-34 Rotor Leakage Reactance (X2)
1-35 Main Reactance (Xh)
1-36 Iron Loss Resistance (Rfe)
1-37 d-axis Inductance (Ld)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed
1-51 Min Speed Normal Magnetising [RPM]
1-52 Min Speed Normal Magnetising [Hz]
1-55 V/f Characteristic - V
1-56 V/f Characteristic - f
1-58 Flystart Test Pulses Current
1-59 Flystart Test Pulses Frequency
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation
1-61 High Speed Load Compensation
1-62 Slip Compensation
1-63 Slip Compensation Time Constant
1-64 Resonance Dampening
1-65 Resonance Dampening Time Constant
1-7* Start Adjustments
1-70 PM startmode
1-71 Start Delay
®
VLT AQUA Drive Programming Guide
Default value
null
null
[3] Auto Energy Optim. VT
[0] Normal
[0] Asynchron
120 %
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] Off
[0] Off
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
100 %
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
30 %
200 %
100 %
100 %
0 %
ExpressionLimit
100 %
5 ms
Parking
0.0 s
®
MG20O602 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
- Uint8
- Uint8
4
- Uint8
- Uint8
- Uint8
0 Int16
-2 Uint16
-2 Uint16
-3 Uint16
1 Uint32
-2 Uint32
0 Uint16
0 Uint16
-2 Uint32
67 Uint16
- Uint8
- Uint8
-4 Uint32
-4 Uint32
-4 Uint32
-4 Uint32
-4 Uint32
-3 Uint32
-6 Int32
0 Uint8
0 Uint16
0 Uint16
67 Uint16
-1 Uint16
-1 Uint16
-1 Uint16
0 Uint16
0 Uint16
0 Int16
0 Int16
0 Int16
-2 Uint16
0 Uint16
-3 Uint8
0 Uint8
-1 Uint16
191
4
