Parameter Description
3.20 Main Menu - Analog I/O Option MCB
109 - Group 26
3.20.1 Analog I/O Option MCB 109, 26-**
The Analog I/O Option MCB 109 extends the functionality
of VLT Refrigeration Drive FC 103 Series frequency
converters, by adding a number of additional,
programmable analog inputs and outputs. This could be
especially useful in Building Management System instal-
lations where the frequency converter may be used as
decentral I/O, obviating the need for an outstation and
thus reducing cost.
Analog I/O Carsd
X42 1 2 3 4 5 6 7 8
Illustration 3.69
®
VLT Refrigeration Drive Programming Guide
Control Card
9 10 11 12 12 13 18 19 27 29 32 33 20 37 39 42 50 53 54 55
®
MG16H102 - VLT is a registered Danfoss trademark
Consider the diagram:
T
M M
M
Illustration 3.68
T
P T
H
Power card
01 02 03 04 05 06
Humidi er steps
or
Cooling steps
157
3 3
