Parameter Description
3.12.6 13-5* States
13-51 SL Controller Event
Array [20]
Option: Function:
Select the boolean input (TRUE or
FALSE) to define the Smart Logic
Controller event.
See 13-02 Stop Event for further
descriptions of choices and their
functions.
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
®
VLT AQUA Drive Programming Guide
13-51 SL Controller Event
Array [20]
Option:
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
13-52 SL Controller Action
Array [20]
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[10] Select preset ref
[11] Select preset ref
[12] Select preset ref
®
MG20O602 - VLT is a registered Danfoss trademark
Function:
Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (defined in
13-51 SL Controller Event) is evaluated as
true. The following actions are available
for selection:
Disabled
*
No action
Select set-up 1 Changes the active set-up (0-10 Active
Set-up) to '1'.
Select set-up 2 Changes the active set-up (0-10 Active
Set-up) to '2'.
Select set-up 3 Changes the active set-up (0-10 Active
Set-up) to '3'.
Select set-up 4 Changes the active set-up (0-10 Active
Set-up) to '4'. If the set-up is changed, it
will merge with other set-up commands
coming from either the digital inputs or
via a fieldbus.
Selects preset reference 0.
0
Selects preset reference 1.
1
Selects preset reference 2.
2
3 3
