Parameter Description
[63] Comparator 3 See parameter group 13-1*. If Comparator
3 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[64] Comparator 4 See parameter group 13-1*. If Comparator
4 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[65] Comparator 5 See parameter group 13-1*. If Comparator
5 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[70] Logic Rule 0 See parameter group 13-4*. If Logic Rule 0
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[71] Logic Rule 1 See parameter group 13-4*. If Logic Rule 1
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[72] Logic Rule 2 See parameter group 13-4*. If Logic Rule 2
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[73] Logic Rule 3 See parameter group 13-4*. If Logic Rule 3
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[74] Logic Rule 4 See parameter group 13-4*. If Logic Rule 4
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[75] Logic Rule 5 See parameter group 13-4*. If Logic Rule 5
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
See 13-52 SL Controller Action. The output
[80] SL Digital
Output A will go high whenever the Smart Logic
Action [38] Set digital out A high is
executed. The output will go low whenever
the Smart Logic Action [32] Set digital out A
low is executed.
[81] SL Digital See 13-52 SL Controller Action. The output
Output B will go high whenever the Smart Logic
Action [39] Set digital out B high is
executed. The output will go low whenever
the Smart Logic Action [33] Set digital out B
low is executed.
[82] SL Digital See 13-52 SL Controller Action. The output
Output C will go high whenever the Smart Logic
Action [40] Set digital out C high is
executed. The output will go low whenever
the Smart Logic Action [34] Set digital out C
low is executed.
[83] SL Digital See 13-52 SL Controller Action. The output
Output D will go high whenever the Smart Logic
Action [41] Set digital out D high is
executed. The output will go low whenever
the Smart Logic Action [35] Set digital out D
low is executed.
[84] SL Digital See 13-52 SL Controller Action. The output
Output E will go high whenever the Smart Logic
Action [42] Set digital out E high is
executed. The output will go low whenever
the Smart Logic Action [36] Set digital out E
low is executed.
®
VLT AQUA Drive Programming Guide
[85]
[160] No alarm
[161] Running
[165] Local
[166] Remote
[167] Start
[168] Drive in hand
[169] Drive in auto
[180] Clock Fault
[181] Preventive
[182] Deragging
[188] AHF Capacitor
[189] External Fan
[190] No-Flow
[191] Dry Pump
[192] End of Curve
[193] Sleep Mode
®
MG20O602 - VLT is a registered Danfoss trademark
SL Digital See 13-52 SL Controller Action. The output
Output F will go high whenever the Smart Logic
Action [43] Set digital out F high is
executed. The output will go low whenever
the Smart Logic Action [37] Set digital out F
low is executed.
Output is high when no alarm is present.
The output is high when the frequency
reverse converter is running counter clockwise (the
logical product of the status bits 'running'
AND 'reverse').
Output is high when 3-13 Reference Site =
reference [2] Local or when 3-13 Reference Site = [0]
active Linked to hand auto at the same time as
the LCP is in Hand on mode.
Output is high when 3-13 Reference Site [1]
reference or Linked to hand/auto [0] while the LCP is
active in Auto On mode.
Output is high when there is an active
command Start command. (I.e.[Auto On] and a start
active command via digital input or bus is active,
or [Hand On].
NOTE
All inverse Stop/Coast commands
must be inactive.
Output is high when the frequency
mode converter is in Hand on mode (as indicated
by the LED light above [Hand on].
Output is high when the frequency
mode converter is in Auto mode (as indicated by
the LED light above [Auto on].
The clock function has been reset to
default (2000-01-01) because of a power
failure.
One or more of the Preventive
Maintenance Maintenance Events programmed in
23-10 Maintenance Item has passed the
time for the specified action in
23-11 Maintenance Action.
Deragging is active.
See 5-80 AHF Cap Reconnect Delay.
Connect
External fan control is active.
Control
A No-Flow situation or Minimum Speed
situation has been detected if enabled in
Low Power Detection. 22-21 Low Power
Detection, 22-22 Low Speed Detection.
A Dry Pump condition has been detected.
This function must be enabled in 22-26 Dry
Pump Function.
Active when an End of Curve condition is
present.
The frequency converter/system has turned
into sleep mode. See Sleep mode,
parameter group 22-4*.
3 3
